GARMIN ECHOMAP UHD 62cv, WW, w/GT24 xdcr



943,06 €
SKU: 010-02329-01
Brand:
Qty: Pre-order
Delivery time: 1-3 days


General

PHYSICAL DIMENSIONS 21.8 x 13.0 x 6.2 cm
DISPLAY SIZE 13.7 x 7.7 cm; 15.2 cm (6.2") diagonal
DISPLAY RESOLUTION 480 x 800 pixels
DISPLAY TYPE WVGA display
WEIGHT 0.7 kg
WATER RATING IPX7
POWER CONSUMPTION 12 W
ANTENNA Internal or external over NMEA 2000
MOUNTING OPTIONS Bail or flush
RECEIVER 5 Hz
GARMIN MARINE NETWORK™ PORTS None

Maps & Memory

PRELOADED MAPS BlueChart® g3 (coastal charts)
ACCEPTS DATA CARDS 1 microSD™ card; 32 GB maximum size
WAYPOINTS Yes
ROUTES Yes
TRACK LOG 50,000 points; 50 saved tracks

Outdoor Recreation Features

TIDE TABLES Yes

Chartplotter Features

GARMIN SONAR COMPATIBLE Yes
SUPPORTS AIS (TRACKS TARGET SHIPS POSITION) Yes
SUPPORTS DSC (DISPLAYS POSITION DATA FROM DSC-CAPABLE VHF RADIO) Yes
ACTIVECAPTAIN COMPATIBLE Yes
SAILING FEATURES Yes

Sonar Features & Specifications

DUAL-FREQUENCY (50/200 KHZ) SONAR CAPABLE Yes
DUAL-BEAM (77/200 KHZ) SONAR CAPABLE Yes
TRANSMIT POWER 500 W (RMS) / 4,000 W (peak to peak)
CHIRP SONAR TECHNOLOGY Yes (Built-in)
CLEARVÜ Yes with CHIRP (built-in)
SIDEVÜ no
MAXIMUM DEPTH 700 metres @ 77 kHz, freshwater
335 metres @ 77 kHz, saltwater
(depth capacity is dependent on water bottom type and other water conditions)
BOTTOM LOCK (SHOWS RETURN FROM THE BOTTOM UP) Yes
WATER TEMPERATURE LOG AND GRAPH Yes
SONAR RECORDING Yes
SONAR HISTORY REWIND Yes

Connections

NMEA 2000® COMPATIBLE Yes
TRANSDUCER PIN NUMBERS Yes
NMEA 0183 INPUT PORTS Yes
NMEA 0183 OUTPUT PORTS Yes
VIDEO INPUT PORTS None
VIDEO OUTPUT PORTS None
WIRELESS CONNECTIVITY Yes
